​​Mechanical Drafting          CAD Service          Rapid Prototyping             3D Printing

 Jacobs Design Drafting provides a ​full range of drafting, 3D modeling and prototype services to meet your needs. Jacobs Design Drafting does not offer engineering services.

  • Convert existing 2D or 3D legacy data into SolidWorks Parts, Assemblies & drawings.
  • Create SolidWorks models from concept sketches, images or written instructions.
  • SolidWorks Assembly drawings with exploded views and integrated Bill of Materials.
  • SolidWorks Animations and Renderings.​
  • SolidWorks Drafting Support - Use SolidWorks Part or Assembly files to create ASME Y14.5 standard fabrication drawings.

SolidWorks Drafting Services


Certifications


While working in the field for over 20 years we have gained valuable experience in many diverse areas of industry. Our experience allows us to provide you with the speed and accuracy required to meet your deadlines and complete your projects. Our experience includes;​​

Design Experience


  • 3D part and assembly modeling, Animations & Renderings

  • Metal Fabrication, Castings, Sheet metal fabrication, Weldments & CNC programming

  • Assembly & Component drawings, Machine shop drawings, GD&T, P&ID's & Assembly Instruction Sheets​

Sample Projects


SolidWorks Drafting Service        CAD Drafting Service           Paper to CAD Conversions           3D Modeling          3D Drafting

  • CSWE: Certified SolidWorks Expert
  • ​CSWP: Certified SolidWorks Professional​
  • CSWP Sheet Metal: Certified SolidWorks Advanced Sheet Metal Specialist​
  • CSWP Weldments: Certified SolidWorks Advanced Weldments Specialist
  • CSWP Surfacing: Certified SolidWorks Advanced Surfacing Specialist​
  • CSWP Drawing Tools: Certified SolidWorks Advanced Drawing Specialist​
  • ​CSWP Mold Tools: Certified SolidWorks Advanced Mold Tools Specialist​
  • CSWA: Certified SolidWorks Associate

We currently hold the following SolidWorks Certifications:​

Jacobs Design Drafting is a Computer-Aided Design Drafting firm that specializes in providing mechanical design, 2D drafting and 3D modeling services. Our CAD drafting services range from simple "paper to CAD" conversion and revision changes to part design and "Top-down" 3D assembly modeling. O​​ur goal is to provide you with a comprehensive CAD service that meets your company's standards and specifications in the time frame that you require. We are located in central South Carolina and serve companies based locally and nation wide.

Welcome to Jacobs Design Drafting!
